（五）spring security之执行流程分析1

SpringSecurity 采用责任链模式，维护了一个很多过滤器组成的过滤器链。

1. DelegatingFilterProxy本身是个Filter，继承自GenericFilterBean，以下DelegatingFilterProxy内的doFilter方法

public void doFilter(ServletRequest request, ServletResponse response, FilterChain filterChain) throws ServletException, IOException {
    Filter delegateToUse = this.delegate;
    if (delegateToUse == null) {
        synchronized(this.delegateMonitor) {
            delegateToUse = this.delegate;
            if (delegateToUse == null) {
                WebApplicationContext wac = this.findWebApplicationContext();
                if (wac == null) {
                    throw new IllegalStateException("No WebApplicationContext found: no ContextLoaderListener or DispatcherServlet registered?");
                }

                delegateToUse = this.initDelegate(wac);
            }

            this.delegate = delegateToUse;
        }
    }

    this.invokeDelegate(delegateToUse, request, response, filterChain);
}

调用this.initDelegate()方法

protected Filter initDelegate(WebApplicationContext wac) throws ServletException {
    String targetBeanName = this.getTargetBeanName();
    Assert.state(targetBeanName != null, "No target bean name set");
    Filter delegate = (Filter)wac.getBean(targetBeanName, Filter.class);
    if (this.isTargetFilterLifecycle()) {
        delegate.init(this.getFilterConfig());
    }

    return delegate;
}

initDelegate方法返回的delegateToUse为FilterChainProxy

调用this.invokeDelegate方法

protected void invokeDelegate(Filter delegate, ServletRequest request, ServletResponse response, FilterChain filterChain) throws ServletException, IOException {
    delegate.doFilter(request, response, filterChain);
}

这里实际是调用FilterChainProxy的doFilter如下：

public void doFilter(ServletRequest request, ServletResponse response, FilterChain chain) throws IOException, ServletException {
    boolean clearContext = request.getAttribute(FILTER_APPLIED) == null;
    if (!clearContext) {
        this.doFilterInternal(request, response, chain);
    } else {
        try {
            request.setAttribute(FILTER_APPLIED, Boolean.TRUE);
            this.doFilterInternal(request, response, chain);
        } catch (Exception var11) {
            Throwable[] causeChain = this.throwableAnalyzer.determineCauseChain(var11);
            Throwable requestRejectedException = this.throwableAnalyzer.getFirstThrowableOfType(RequestRejectedException.class, causeChain);
            if (!(requestRejectedException instanceof RequestRejectedException)) {
                throw var11;
            }

            this.requestRejectedHandler.handle((HttpServletRequest)request, (HttpServletResponse)response, (RequestRejectedException)requestRejectedException);
        } finally {
            SecurityContextHolder.clearContext();
            request.removeAttribute(FILTER_APPLIED);
        }

    }
}

然后获取过滤器链，调用doFilterInternal方法

private void doFilterInternal(ServletRequest request, ServletResponse response, FilterChain chain) throws IOException, ServletException {
    FirewalledRequest firewallRequest = this.firewall.getFirewalledRequest((HttpServletRequest)request);
    HttpServletResponse firewallResponse = this.firewall.getFirewalledResponse((HttpServletResponse)response);
    List<Filter> filters = this.getFilters((HttpServletRequest)firewallRequest);
    if (filters != null && filters.size() != 0) {
        if (logger.isDebugEnabled()) {
            logger.debug(LogMessage.of(() -> {
                return "Securing " + requestLine(firewallRequest);
            }));
        }

        FilterChainProxy.VirtualFilterChain virtualFilterChain = new FilterChainProxy.VirtualFilterChain(firewallRequest, chain, filters);
        virtualFilterChain.doFilter(firewallRequest, firewallResponse);
    } else {
        if (logger.isTraceEnabled()) {
            logger.trace(LogMessage.of(() -> {
                return "No security for " + requestLine(firewallRequest);
            }));
        }

        firewallRequest.reset();
        chain.doFilter(firewallRequest, firewallResponse);
    }
}

在doFilterInternal中创建了过滤器链对象VirtualFilterChain并调用VirtualFilterChain的doFilter方法执行自定义的过滤器集合，当自定义的过滤器集合执行完毕后，再执行原有的过滤器链

public void doFilter(ServletRequest request, ServletResponse response) throws IOException, ServletException {
    if (this.currentPosition == this.size) {
        if (FilterChainProxy.logger.isDebugEnabled()) {
            FilterChainProxy.logger.debug(LogMessage.of(() -> {
                return "Secured " + FilterChainProxy.requestLine(this.firewalledRequest);
            }));
        }

        this.firewalledRequest.reset();
        this.originalChain.doFilter(request, response);
    } else {
        ++this.currentPosition;
        Filter nextFilter = (Filter)this.additionalFilters.get(this.currentPosition - 1);
        if (FilterChainProxy.logger.isTraceEnabled()) {
            FilterChainProxy.logger.trace(LogMessage.format("Invoking %s (%d/%d)", nextFilter.getClass().getSimpleName(), this.currentPosition, this.size));
        }

        nextFilter.doFilter(request, response, this);
    }
}
